Mercedes W12

A place to discuss the characteristics of the cars in Formula One, both current as well as historical. Laptimes, driver worshipping and team chatter do not belong here.
User avatar
F1Krof
94
Joined: 22 Feb 2016, 21:17

Re: Mercedes W12

Post

ScrewCaptain27 wrote:
12 Mar 2021, 22:26
Apparently there is a channel underneath the gearbox similar to the one found on the Ferrari.

Link to article (Italian):https://it.motorsport.com/f1/news/f1-me ... a/5700445/
“Today was a bad start to the season - admitted the chief of track engineers Andrew Shovlin - we are not happy with how the car is performing and it is quite clear that we have work to do. We are behind our test program and we need to find some balance and speed, let's see how it will go over the next two days ”.

Does he mean the issue with the gearbox or are they worries on a more general feel?
Wroom wroom

User avatar
Mr.G
34
Joined: 10 Feb 2010, 22:52
Location: Slovakia

Re: Mercedes W12

Post

Sevach wrote:
12 Mar 2021, 09:12
https://pbs.twimg.com/media/EwQtlGYXEAc ... ame=medium

https://pbs.twimg.com/media/EwQpj_hXIAI ... =4096x4096

Is it me or the FW looking more "Ferrarish" in style.
Is this type of "closed" geometries on floor legal? Wasn't there change of rules to avoid this or was it pushed to the next year?
Art without engineering is dreaming. Engineering without art is calculating. Steven K. Roberts

User avatar
diffuser
236
Joined: 07 Sep 2012, 13:55
Location: Montreal

Re: Mercedes W12

Post

ScrewCaptain27 wrote:
12 Mar 2021, 22:26
Apparently there is a channel underneath the gearbox similar to the one found on the Ferrari.

Link to article (Italian):https://it.motorsport.com/f1/news/f1-me ... a/5700445/
So i saw hat artical and was thinking to myself .... Does that fall under the double diffuser?

Just_a_fan
Just_a_fan
593
Joined: 31 Jan 2010, 20:37

Re: Mercedes W12

Post

diffuser wrote:
12 Mar 2021, 23:37
ScrewCaptain27 wrote:
12 Mar 2021, 22:26
Apparently there is a channel underneath the gearbox similar to the one found on the Ferrari.

Link to article (Italian):https://it.motorsport.com/f1/news/f1-me ... a/5700445/
So i saw hat artical and was thinking to myself .... Does that fall under the double diffuser?
Simple answer: no.

A double diffuser connects the underfloor space with the above floor space. That requires a hole and holes are illegal in this situation.
If you are more fortunate than others, build a larger table not a taller fence.

User avatar
Stu
Moderator
Joined: 02 Nov 2019, 10:05
Location: Norfolk, UK

Re: Mercedes W12

Post

Just_a_fan wrote:
12 Mar 2021, 23:55
diffuser wrote:
12 Mar 2021, 23:37
ScrewCaptain27 wrote:
12 Mar 2021, 22:26
Apparently there is a channel underneath the gearbox similar to the one found on the Ferrari.

Link to article (Italian):https://it.motorsport.com/f1/news/f1-me ... a/5700445/
So i saw hat artical and was thinking to myself .... Does that fall under the double diffuser?
Simple answer: no.

A double diffuser connects the underfloor space with the above floor space. That requires a hole and holes are illegal in this situation.
Wonder what feeds that outlet?
Very groovy shape to the top of the diffuser.
Interesting floor edge treatment.
Perspective - Understanding that sometimes the truths we cling to depend greatly on our own point of view.

User avatar
dans79
267
Joined: 03 Mar 2013, 19:33
Location: USA

Re: Mercedes W12

Post

F1Krof wrote:
12 Mar 2021, 22:42
ScrewCaptain27 wrote:
12 Mar 2021, 22:26
Apparently there is a channel underneath the gearbox similar to the one found on the Ferrari.

Link to article (Italian):https://it.motorsport.com/f1/news/f1-me ... a/5700445/
“Today was a bad start to the season - admitted the chief of track engineers Andrew Shovlin - we are not happy with how the car is performing and it is quite clear that we have work to do. We are behind our test program and we need to find some balance and speed, let's see how it will go over the next two days ”.

Does he mean the issue with the gearbox or are they worries on a more general feel?
I'm sure a little of everything.

The transmission issue meant they lost a lot of valuable set-up evaluation time. For example The Merc in the afternoon wasn't much different than the Red Bull in the morning. By the time the afternoon session came around Red Bull had analyzed the data from the morning session and made appropriate changes.

The weather in the afternoon wasn't overly conducive to figuring ont issues either.
201 105 104 9 9 7

User avatar
diffuser
236
Joined: 07 Sep 2012, 13:55
Location: Montreal

Re: Mercedes W12

Post

Stu wrote:
13 Mar 2021, 00:01
Just_a_fan wrote:
12 Mar 2021, 23:55
diffuser wrote:
12 Mar 2021, 23:37


So i saw hat artical and was thinking to myself .... Does that fall under the double diffuser?
Simple answer: no.

A double diffuser connects the underfloor space with the above floor space. That requires a hole and holes are illegal in this situation.
Wonder what feeds that outlet?
Very groovy shape to the top of the diffuser.
Interesting floor edge treatment.

So you're implying that isn't a hole, just a triangular shape protruding from the floor? Vortex generator if you wish ?

neilbah
neilbah
14
Joined: 10 Jul 2009, 20:36

Re: Mercedes W12

Post

an outlet from within the body rather than under the floor at a guess

FDD
FDD
80
Joined: 29 Mar 2019, 01:08

Re: Mercedes W12

Post

diffuser wrote:
13 Mar 2021, 00:42
Stu wrote:
13 Mar 2021, 00:01
Just_a_fan wrote:
12 Mar 2021, 23:55

Simple answer: no.

A double diffuser connects the underfloor space with the above floor space. That requires a hole and holes are illegal in this situation.
Wonder what feeds that outlet?
Very groovy shape to the top of the diffuser.
Interesting floor edge treatment.
It looks to me like

So you're implying that isn't a hole, just a triangular shape protruding from the floor? Vortex generator if you wish ?
It looks to me like a hole, maybe it is fed through the sidepod somewhere, difficult to say from this picture. Ferrari used something similar on SF71H.
https://www.autosport.com/f1/news/the-s ... 6/5320906/

User avatar
Zynerji
110
Joined: 27 Jan 2016, 16:14

Re: Mercedes W12

Post

I mean, we see what the airboxes are split like, and OMG brake ducts 🙄, so aren't we assuming that the inside of the sidepod is the same (post radiator)?

This seems so simple, yet obvious, thus it's brilliance. (The outlet, that is.😏)

MKlaus
MKlaus
5
Joined: 30 Aug 2020, 08:22

Re: Mercedes W12

Post

there is a hole on the floor of the W12 at the end of side pods.

https://it.motorsport.com/f1/news/f1-me ... a/5700445/

The mysterious blowing
The image of Giorgio Piola is eloquent: by clearing some details, the vent of air emerged that catches the flow from under the bottom and blows it on the central channel of the extractor, taking up the solution of the "double diffuser" that he had introduced years ago Ferrari and that Mercedes was able to develop better than in Maranello.

Now we have reached the extreme of the concept thanks to the new gearbox that has allowed to generate a new air passage under the car, useful for creating downforce with the car body.

The W12 was born around this well-hidden novelty: it is not surprising, therefore, if the black arrow just put the wheels on the ground did not meet the expectations of the world champion.

User avatar
PlatinumZealot
559
Joined: 12 Jun 2008, 03:45

Re: Mercedes W12

Post

Erm that diffuser dop has been on cars for years now. Some times teams shroud it sometimes not. Check any photos of the floors removed over the years and you can see how teams sometimes wall it off or just leave it exposed like Merc has here.
🖐️✌️☝️👀👌✍️🐎🏆🙏

Racing Green in 2028

zibby43
zibby43
613
Joined: 04 Mar 2017, 12:16

Re: Mercedes W12

Post


DarthPlagueisTheVise
DarthPlagueisTheVise
42
Joined: 21 Sep 2020, 14:10

Re: Mercedes W12

Post

So did merc also spend their tokens on a new gearbox aswell?
Technical Noob

User avatar
Morteza
2308
Joined: 10 Feb 2010, 18:23
Location: Bushehr, Iran

Re: Mercedes W12

Post

Via AMuS
